Hartmann HRS4-252-GS 22x9.5 ET50 Wheel for Audi 4L Q7 and VW Touareg
Since 1978, Hartmann Wheels has focused on bringing the highest quality wheels to the US market. Hartmann wheels are produced in a modern, state-of-the-art German owned foundry. Hartmann utilizes a low pressure casting process which produces a high performance wheel equal in strength and finish quality to OEM Audi and VW wheels. The wheels are heat treated for increased strength and are tested to JWL, VIA, and TUV standards.
Hartmann wheels are designed by Germany's finest engineers. The Hartmann HRS4-252-GS wheel is an OEM-inspired design featuring 7 split spokes which curve inwards to meet the centercap. The HRS4-252-GS wheels are finished with a gloss silver paint, and are designed to accept OEM lug bolts, OEM centercaps, and OEM TPMS senders.
Hartmann carefully selects their wheel offsets "ET"* to provide a fitment which will clear the brake caliper and suspension components, widen the track for better handling and aesthetics, and not allow the tire to contact the fender or fender liner during cornering or suspension travel, even on lowered vehicles. Fitment is backed by a money back guarantee. *ET: from German "Einpresstiefe" (translates into "Insertion Depth") referred to as "Offset" in English: A measurement in mm of the distance between the center line of the wheel and the mounting surface of the wheel which contacts the hub face.
HARTMANN HRS4-252-GS FEATURES:
Gloss Silver Finish
OE quality and strength
Uses OEM R14 ball seat lug bolts
Accepts OEM centercaps
Low pressure cast aluminum alloy
Heat treated for high strength
Tested to JWL, VIA, and TUV standards
HARTMANN HRS4-252-GS SPECIFICATIONS:
Bolt Pattern: 5x130
Centerbore: 71.60 mm
Centerbore Chamfer: 3 mm
Lug Type: 14x1.5 R14 Ball Seat
Centercap Audi: 4B0 601 170 A 7ZJ
Load Rating: 900 Kg (1,984 Lbs)
Weight: 17.06 Kg (37.6 Lbs) +/- .5 Kg
FITMENT GUIDE: The Hartmann HRS4-252-GS wheel in 22x9.5" ET50 fits the following vehicles:
